From the installation position, the conveyor belt sweeper can be divided into the first sweeper, the second sweeper and the empty segment sweeper. The three belt sweepers are matched with each other, which is conducive to exert the cleaning effect of conveyor belt and solve the problem of belt adhesive material.This paper will focus on the empty section conveyor belt sweeper installation instructions.
Installation instructions for empty section conveyor belt sweeper:
1. Before installing the empty segment sweeper, first turn off the power supply of the belt conveyor and mark it.Leave the belt conveyor in a state of shutdown.This is an important step.
2. Place the empty segment sweeper on the conveyor belt.Check both ends (that is, where the mounting rack meets the architecture) for architectural interference.
3. Connect the mounting shaft to the empty segment sweeper bracket.
4. Connect the mounting rack to the mounting shaft.
5. After installation, run the conveyor equipment and check the performance of the empty segment sweeper.
Run the conveyor belt and check whether the empty conveyor belt sweeper is in normal operation.
If the empty segment sweeper is not found to be working properly, a final adjustment is required.
